KIRSCH Blood Plasma Freezer BL 730 ULTIMATE

KIRSCH Blood Plasma Freezer BL 730 ULTIMATE

£16,032.73
£0.00 £16,032.73
Sale Sold out
Version
Product overview
  • Medical device according to DIN 13485
  • Minimum temperature deviations
  • Efficient convection cooling and door frame heating
  • Precise temperature regulation
  • Available in various sizes and versions

KIRSCH Blood Plasma Freezer

The energy-saving KIRSCH blood plasma freezer complies with DIN ISO 13485 and DIN 58375 and is equipped with the PRO-ACTIVE control system which, in addition to permanent monitoring of all performance data, ensures minimal temperature deviations between the warmest and coolest storage locations. At the same time, efficient recirculating air cooling ensures even temperature regulation without strong temperature fluctuations. This ensures constant and uniform cooling of the blood plasma samples.


To protect the temperature control from unauthorised access, it is protected with a key switch or RFID/password, depending on the version. The time-consuming documentation of the minimum and maximum temperature is minimised for the specialist staff, as the freezer is equipped with an integrated memory whose data can be easily read and archived. In the event of a power failure or other malfunctions that may cause deviations in cooling, an acoustic and visual signal indicates the malfunctions. If required, alarm forwarding to a mobile phone, for example, is also possible to receive notification of alarms anywhere and anytime.


Product Details

  • KIRSCH Blood Plasma Freezer
  • Complies with DIN ISO 13485 and DIN 58375
  • Operates with the PRO-ACTIVE control system
  • Permanent monitoring of all performance data
  • Minimum temperature deviations between storage locations
  • Precise temperature regulation with the aid of second PT-1000 temperature regulators
  • 5 aluminium drawers, height-adjustable
  • Drawers on smooth-running roller runners with locking mechanism
  • Stacking height of drawers: approx. 23 cm
  • Display at eye level
  • With easy-opening ergonomics door opener
  • Recirculating air cooling ensures even temperature regulation
  • Adjustable feet to compensate for uneven floors
  • Energy-saving insulation (70 mm thick)
  • Self-closing and lockable door
  • Replaceable plastic magnetic seal frame
  • Interior lined with smooth aluminium
  • Outer casing made of galvanised and rust-protected sheet steel
  • White powder-coated and scratch-resistant
  • Plug cable length: approx. 3 m
  • Automatic rapid defrosting possible
  • Condensation evaporation in the refrigeration machine room
  • Electronic and access-protected temperature regulation
  • With minimum and maximum memory
  • Audible and visual alarm in case of power failure or malfunctions
  • Alarm forwarding can be set up
  • Forced-air cooling machine, hermetically sealed
  • Door frame heating prevents the door from freezing shut
  • Available in various variants

Differences between PRO-ACTIVE and ULTIMATE


 PRO-ACTIVE ULTIMATE
Display Membrane keypad with digital temperature display and min./max. temperature memory. Capacitive touch display in elegant glass design. Graphic display of the temperature curve and the min./max. temperature.
Temperature Regulation Protected by key switch. Protected by RFID/password.
Alarm Forwarding Via potential-free contact (e.g. on mobile phone with GSM module or connection to central control technology). Via network and potential-free contact (e.g. connection to central control technology).
Data Documentation Reading via USB interface by means of USB stick and software KIRSCH Datanet Digital - can be read via network (PC-KIT-NET) and KIRSCH Datanet software.
Access Control No. Yes - with protocol function.
Warning Function Visual and acoustic alarm signal. Visual and acoustic alarm signal. In the event of a power failure, the monitoring unit remains in operation for approx. 30 h thanks to the rechargeable battery.

Technical Specifications


 BL 530 BL 730
Capacity 500 litres 700 L
Temperature Setting -32 °C
Power Input 740 watts 790 watts
Voltage 220-240 V, 50 Hz
Standard Consumption 10.81 kWh/24 h
 11.1 kWh/24 h
Permissible Ambient Temperature +10 °C to +32 °C
Heat Emission(max.) 827 watts 860 watts
External Dimensions (incl. wall distance & door handle) 77 x 76 x 196 cm (W x D x H)* 77 x 98 x 196 cm (W x D x H)*
Inner Dimensions 62 x 56 x 140 cm (W x D x H)* 62 x 77 x 140 cm (W x D x H)*
Outer Dimensions with Door Open at 90° 77 x 144 cm (W x D) 77 x 166 cm (W x D)
Light Drawer Dimensions 56 x 39 x 10 cm (W x D x H) 56 x 60 x 10 cm (W x D x H)
Max. Load Drawer 50 kg
Weight 161 kg (net); 183 kg (gross) 202 kg (net); 237 kg (gross)

*Values may vary minimally depending on the variant (see product data sheet)
